Focused image of a used mecal nike machining center for aluminium and pvc profiles.
Side view of a used Mecal Nike 4 axis machining center showing the Y axis clamps
Image of the clamping system on a used mecal 309 Nike machining center
Image of clamp and Z axis machine tool head for the mecal mc309 aluminium machining center
Image of a used mecal aluminium machining center PC control unit with samsung monitor, mouse and keyboard
Image of a used mecal mc209 nike aluminium and pvc machining center focusing on the Z axis tool head

Refurbished 2011 Mecal MC309 Nike Machining Center – NOW SOLD

MU-DPM version with automatic magazine & clamps positioned by head
Main spindle does all work with full use of the magazine
Open ends to allow machining of longer pieces
Full CAM-3d software
3490mm working length
Option for mist extraction system
Add to quote
Category:

Mecal MC 309 Nike 3+1 Axis Machining Center – SOLD

£ POA call 01384 264950 or mail cwilson@addisonsaws.co.uk

2011 profile machining center 3+1 axis.

For high speed machining of Aluminium – Steel – Brass – Copper and PVC materials. Used in numerous applications including;

  • Windows & doors
  • Bi-fold doors
  • Curtain walling
  • Automotive
  • Aerospace
  • Engineering
  • internal partitions
  • sign manufacturing
  • air conditioning
  • refrigeration



We have installed these machines for many different uses. They can machine slots, pockets, holes, and custom shapes. They also handle end slotting, profiling, tapping, rigid tapping, drilling, and flow drilling.

Machine Specification
X-axis stroke 3500 mm
Positioning speed X-axis70 mm/1’
Y-axis stroke370 mm
Positioning speed Y-axis30 m/1’
Z-axis stroke348 mm
Positioning speed Z-axis
A axis stroke± 90° Pneumatic with auto position stops and manual set stops for intermediate angles
Electro spindle rated power3,8 kW
Cooling systemAir
Tool holder coneISO30
Max rotation speed18000 rpm
Weight± 2200 kg

Subject to technical changes.



*Machine only price, excludes VAT, commissioning and delivery.

Mist Extraction

Virtually Mandatory now mist extraction is an important option to consider either supplied with a new machine or easy retro-fit. Our Italy Vacuum is the most efficient and cost effective solution. Lower purchase cost than leading brand, no scheduled servicing costs as all filters with the exception of the HEPA filter can be user cleaned with an air gun or just warm water, and finally the extraction performance is industry leading by comparison.

mecal barcode reader for machining centres
Bar Code Reader

For receiving job data when integrated with a double mitre saw that has the thermal label printer. The job data is usually provided by external software.

Mecal job simulator software
Simulator

Job simulator software which shows an accurate simulation of the actual job in real time very graphically. Indicating timings and potential process errors.

5 position tool magazine

5-position tool magazine on the machine. It may contain tools for drilling, milling, tapping, end-milling. A second magazine can also be added on the right side.

4 axis machining capability
4 Axis Machining

The machine has 3+1 axis machining. It can rotate the A axis using a pneumatic rotating table with auto stops at -90deg 0 deg +90 deg and manual stops for intermediate angles.

Mecal Falcon machining centre clamps for securing profile in place.
Clamping

6 clamps

MU-DPM version is the most popular choice. In this model, the clamps move automatically into position. This happens through the machining head carriage.

Mecal cnc machining centre material loading zones
Loading Zones

Single loading zone with 2 zero reference stops allowing 2 different jobs of appropriate length to be worked. For a full-length job, the machine can be opened. This allows for machining profiles that are longer than the Z axis.

Mecal cad cam 3D image
Mecal CAD CAM 3D

Designed to be the most advanced and easy to use system currently available. All of the basic programming is available with pre-loaded macros which are applied by a simple drag and drop process. The 3D graphic shows a clear and accurate view. You can look at it from any angle to find errors. It also shows how to correctly load the workpiece.

Mecal external connection image
External Connections

We can connect to many external window packages, including Schucal-Logikal. Sometimes, a linking program is needed for an extra cost.

The converter imports IGES files in completed SW CAD 3D and creates the program to process the job. This function is in high demand from industrial clients using Inventor-Solid Works and Solid Edge type programs.

Mecal-Nike-Data-Sheet.pdf
