Oz Machinery Garnet-Mini
A very compact and economical 3 axis cnc machining centre or advanced copy router for lock preparation and similar milling applications in aluminium and pvc extrusions. Can be supplied with optional Comet GM, NC powered length stop for automatic positioning of the profile.
| MACHINING LENGTHS | |
| X Axis (Longitudinal) | 350 mm |
| Y Axis (Lateral) | 150 mm |
| Z Axis (Vertical) | 120mm |
| POSITIONING SPEED | |
| X Axis (Longitudinal) | 30 m/min |
| Y Axis (Lateral) | 30 m/min |
| Z Axis (Vertical) | 30 m/min |
| SPINDLE | |
| Spindle with cooling fan | 3 |
| Maximum power | 3 kW |
| Maximum rotation speed | 18.000 rpm |
| Tool holder | ER20 |
| PROFILE POSITIONING | |
| Right and left profile gauge | Standard |
| Laser indication | Standard |
| Axis data | |
| Xmax/ Xmin (Longitudinal) | – / 660 mm |
| Ymax / Ymin (Lateral) | 150 mm / – |
| Zmax/ Zmin (Vertical) | 120 mm / – |
| CONTROL UNIT | |
| Touchscreen | 10″ |
| Data transfer via USB | Standard |
| Smart CAM post processing | Optional |
| OPERATIONAL AREA | |
| Clamps, standard quantity | 4 |
| Automatic lubrication in processing area | Standard |
| Guard cabin for machining area | Standard |
